RatRig V-Core 4 – 300

PROGRESSIVE UPGRADE PATH

EASILY UPGRADE STANDARD INTO HYBRID AND THEN HYBRID INTO IDEX – CONVERSION BETWEEN MODES IS JUST A MATTER OF ADDING A FEW PARTS. NO REBUILD IS NECESSARY.

• Machine Kit – Includes all the frame elements, mechanical/kinematic components and machine wiring:
  1 x Rat Rig V-Core 4.0 – Machine Kit v1.02 – 300
• Complete Printed parts bundle for a COREXY machine – Hybrid and IDEX printed parts not included:
• 1 x Rat Rig V-Core 4.0 – Base Printed Parts Bundle (ABS – Black & Green)
• ELECTRONICS ENCLOSURE (INCLUDES BOX, WIRING, FANS & HARDWARE):
  1 x Rat Rig V-Core 4.0 – Aluminium Electronics Enclosure Kit
• Bed plate (Swap the default option for a V-Core 3 bed at a discounted price):
  1 x Rat Rig V-Core 4.0 – Bed Plate – Milled cast tooling plate – 329*329*6mm
• Heater Pad (SSR Required):
  1 x C-LIN SSR 40A480VAC Solid State Relay Input 3V~32VDC 40DA

  1 x Keenovo 280x280mm 220V 600W Silicone Heater Bed Pad w/ NTC 100K Thermistor and Thermal Fuse
• Print surface (Includes magnetic sheet):
  1 x FlexPlate PRO Set – Black Textured PEI 310 x 310 mm – Double Sided
• Electronics – Controller Setup and Wiring (RPI is required to run RatOS):
  1 x BigTreeTech Octopus V1.1 Motherboard (board only – no drivers)

  1 x BigTreeTech EBB42 USB/CAN Toolboard v1.2 (Without Max)

  5 x BigTreeTech TMC2209 Driver
• Electronics – Sensors (Choose either the Beacon or the SuperPinda):
  2 x Rat Rig Endstop v1.1 – Omron – NC

  1 x Beacon Sensor Rev H – by Beacon3D (Klipper only – USB Cable Included)
• Electronics – Toolhead:
  1 x Phaetus Rapido 2.0 Plus UHF Hotend – Black – 2000mm Cable

  1 x LDO Orbiter V2.0 Extruder

  1 x Fan – 4010mm Axial Brushless 24V DC – 140mm Cable – GDSTime (Double Ball Bearing)

  1 x Fan – 4028 Axial – NIDEC W40S12BS2E5-57T04HF9 (12V 1.61A 25000RPM)
• Motors (NEMA HT REQUIRED FOR XY AXIS):
  3 x Nema 17 Stepper Motor – 48mm – 1.8degree/step, 76oz-in (LDO-42STH48-2504AC)

  2 x Nema 17 Stepper Motor – HT – 48mm – (1.8º, 76oz-in, 35mm shaft)
• Power Supply:
  1 x Power Supply Weho – 250Watt 24V – Fanless
• Performance Upgrade (Required for IDEX):
  1 x Rat Rig V-Core 4.0 – HYBRID Upgrade Kit (CoreXY to Hybrid)
