Therm^2 By: not salmon manඞ

How to assemble Therm^2

1. Unboxing and Verification

Open the Therm^2 package and ensure all components are present.

2. Pinout

3. Flashing Klipper

• SSH into your Raspberry Pi.
• Go to the Klipper directory.

cd klipper

• Clean the remaining files from the previous build.

make clean

• Choose the options for the build.

make menuconfig

Use the following options:

Press Q then Y to save and quit the menu.

• Build.

make

• Connect your Therm^2 to your Raspberry Pi while holding down the BOOT button.
• Use lsusb and find the device in DFU mode.
• Flash it. Replace the ID with the ID from the previous step.

make flash FLASH_DEVICE=1234:5678

• When finished, press the RESET button on your Therm^2.
• Check the serial connections and find the path starting with /dev/serial/by-id/usb-Klipper_stm32f042.

ls /dev/serial/by-id/*

4. Klipper Config

therm2-config.cfg
