Mellow Fly Pi V2 With UTOC 40Pin GPIO Expandable EMMC For DIy Klipper I3 CoreXY 3D Printer CAN SB2040 SHT36 Replace Raspberry PI

The newly updated FLY-Pi 2 motherboard has the following features, making it a convenient choice for project users who prefer to use Klipper or RRF firmware:

If you have any questions, you can enter our server to communicate //discord.gg/7J26EsFURQ

More detailed information about the board can be found at //mellow.klipper.cn/?lang=en#/board/fly_pi_v2/

Redesigned to Resemble Raspberry Pi 4: The design has been revamped to have the same appearance as the Raspberry Pi 4, making it convenient for customers to use it as a replacement for Raspberry Pi 4.

Innovative FPC Connection for HDMI Screen: The board now includes a new FPC connection design for HDMI screens, allowing a direct connection to the Fly-HDMI screen using a single FPC cable, replacing HDMI and USB cables, similar to DSI screen connections.

FPC Connection for 3.5-inch TFT Screen: The motherboard also features an FPC connection for a 3.5-inch TFT screen, offering customers a low-cost screen option for Klipper, enhancing its accessibility and usability.

Built-in CAN Chip for Communication: A CAN chip has been added for motherboard communication, eliminating the need for additional expansion boards. Also, a 3.5mm audio jack has been included to provide more usability options.

1GB DDR Memory: FLY-Pi 2 now comes with 1GB of DDR memory, offering more memory for a full-fledged desktop based on Armbian. This means users can run more applications and resource-intensive programs without performance issues.

Compatibility with Klipper and RRF Firmware: FLY-Pi 2 is designed to be compatible with Klipper and RRF firmware, giving users greater flexibility in choosing the firmware that best suits their needs.

EMMC+SDIO Expansion: FLY-Pi 2 also includes EMMC+SDIO expansion, supporting WiFi and 32G storage functionality. This means users can add WiFi connectivity and storage to their projects without the need for extra expansion boards.

In summary, the FLY-Pi 2 motherboard is a versatile and convenient choice for project users who enjoy using Klipper or RRF firmware. With increased memory capacity, support for various firmware, built-in WiFi and storage features, and the ability to use an FPC connection for a 3.5-inch TFT screen, it offers a more comprehensive and powerful solution compared to Raspberry Pi.

4*Cortex high-performance processor

RAM: 1024M DDR3

GPU: ARM Mali450

MicroSD

USB Host2.0*3 USB-OTG*1

FPC-SPI*1

40PIN*1(Uart*2,Spi*1)

HDMI*1

FPC-HDMI*1

Emmc+Sdio extension*1

Ethernet: 100M
5V Controllable Fan Port*1

VCC port*1

Can port (Direct connection to Can tool board)*1

This Fly-M2WE board contains 16G eMMC and 5g Wifi, providing more stable system operation and faster network transmission. Factory built-in linux system and klipper software, so plug and play.

1. Integrated eMMC storage chip and 2.4G/5G dual-band WiFi

2. The read and write speed of eMMC is 2 times higher than that of TF Card (C10)

3. 5G WiFi uploads files on the web page ≈ 16MB/s

4. The system runs more stably and faster

The M2-2.4G Wifi board can be connected to the fly pi 2 through the m2 interface, providing a transmission speed of 6m/s, which is a cheap wifi solution
