Toro-Titanium-Tube RatRig V-Core 4

$145.50$176.25

or
SKU: N/A Categories:
Toro-Titanium-Tube RatRig V-Co...

$145.50$176.25

Select options

The Toro-Titanium-Tube, a lightweight gantry support structure, significantly reduces your printer’s moving mass. Its standout feature is the precision of titanium’s thermal expansion coefficient, which closely mirrors that of steel. This precision eliminates the bi-metal effect of the x-axis, ensuring a flawless first layer with every print.

Comparison with aluminium extrusion

625mm525mm425mm
2020 Extrusion311g261g211g
Toro-Titanium-Tube207g178g
Weight saving104g
(33%)
83g
(32%)
Due to the constant optimization of the manufacturing process the weight of the shipped tubes might be slightly higher or lower than the values stated above.
One thing that has to be pointed out: Due to the nature of Titanium it is very hard to process. As a result it is not as straight/flat as our Aluminium tubes. So you if you want a flat mesh (which is not really necessary), you have to use Kapton Tape. But since you have no time depended deformation anymore, Klippers Bed Mesh algorithm can be applied to compensate this. There were intensive Beta Tests with users from the community and they have not found this to be a big problem. However, the very stable first layer was noted as a big improvement over their previous tubes. Due to the tolerances might be necessary to increase the width/height of the rectengular cutout of the XY joiners slight. Altough most of the testers simply pushed them in with a little force.
