BIGTREETECH BTT Octopus Max EZ

BIGTREETECH BTT Octopus Max EZ

128.00 AUD

BIGTREETECH Octopus MAX EZ, a 32-bit motherboard, is an upgraded version of Octopus Pro developed by the 3D printing team of Shenzhen Big Tree Technology Co., Ltd. Its self-developed stepper motor sockets enhance safety and user experience, and it adds a series of features that Octopus Pro does not have, greatly enhancing its DIY capabilities.

Key Features:

1. 32-bit 550 MHz ARM Cortex-M7 series STM32H723ZET6 MCU 2. Onboard BOOT button to enable DFU mode to update the bootloader 3. The thermistor circuit is protected to prevent MCU damage from shorted heated bed and heater cartridge connections 4. Selectable voltage (24V, 12V, 5V) for CNC fan, no more need for external stepdown thus preventing board damage from user error 5. Upgraded with eFuse protection, which response faster with strong protection, effectively protecting the motherboard from being damaged caused by short circuits, over-current, electric spark, etc. 6. MCU firmware can be upgraded via SD card, or use DFU via Klipper's make flash command 7. 10 EZ driver sockets, working with the pinless driver, safer to use; Onboard SPI and UART, can be used by simply setting in the firmware, no need for a jumper 8. Support power loss recovery, filament runout sensor, CAN, auto power-off, BL Touch, RGB, etc 9. Replaceable fuse for easy maintenance 10. 3 x 4 pins fan ports, also for connecting the water cooling system 11. Onboard proximity switch port, supports NPN and PNP types, 24V, 12V, and 5V voltage selectable 12. Onboard SPI interface for connecting acceleration sensor to enable Klipper's input shaping BIGTREETECH BTT Octopus Max EZ – picture 1BIGTREETECH BTT Octopus Max EZ – picture 2BIGTREETECH BTT Octopus Max EZ – picture 3BIGTREETECH BTT Octopus Max EZ – picture 4BIGTREETECH BTT Octopus Max EZ – picture 5BIGTREETECH BTT Octopus Max EZ – picture 6BIGTREETECH BTT Octopus Max EZ – picture 7BIGTREETECH BTT Octopus Max EZ – picture 8BIGTREETECH BTT Octopus Max EZ – picture 9BIGTREETECH BTT Octopus Max EZ – picture 10BIGTREETECH BTT Octopus Max EZ – picture 11BIGTREETECH BTT Octopus Max EZ – picture 12BIGTREETECH BTT Octopus Max EZ – picture 13BIGTREETECH BTT Octopus Max EZ – picture 14BIGTREETECH BTT Octopus Max EZ – picture 15BIGTREETECH BTT Octopus Max EZ – picture 16BIGTREETECH BTT Octopus Max EZ – picture 17BIGTREETECH BTT Octopus Max EZ – picture 18
